Applications

• For residential homes: faucets, showers, garden and lawn irrigation.
• Light commercial use
• Greenhouses
• Irrigation systems
• Car wash stations
• Supermarket vegetable sections
• Water supply: from roof-mounted reservoirs, above-ground and underground tanks, and wells (up to 8 m depth).
• Pressure boosting: from the central water supply system.

Features and Advantages

Built-in pump, motor, diaphragm tank, pressure and flow sensors, dry-running protection, controller, and non-return valve – all integrated into one compact housing.

• Easy installation and start-up
  Only requires pipe connection, pump priming, and power supply connection. Advanced parameter configuration can be done through the Grundfos GO REMOTE app.
• Bluetooth control
  The unit has built-in two-way Bluetooth communication with the Grundfos GO app, enabling easy monitoring, remote control, and diagnostics.
• Twin Pump functionality
  Simultaneous control of two pumps is possible using Duty/Assist or Duty/Standby modes, easily configurable via the application.
• Protection mechanisms
• Dry-running protection
• Anti-cycling protection in case of small flow demand
• Maximum operating time limit
• Motor overheating and blockage protection
• Long service life and minimal maintenance
  The pump does not require regular servicing; it is only recommended to keep it clean, check the non-return valve, and clean the ventilation openings.

Technical Details

• Type: SCALA1 5-25
• Maximum suction depth: 8 m
• Noise level: low noise level comparable to a domestic water heater
• Connection to Grundfos GO app: Bluetooth
• Twin system: supported
